Product Description
Dahua XVR5108H-4KL-X-8P — 8-channel Penta-brid PoC DVR
This recorder suits retrofits and mixed-estate jobs where existing HDCVI, AHD, TVI or CVBS cameras need to stay in service alongside new IP additions. Eight channels accept any of those five formats, and hybrid mode extends capacity to 12 IP inputs (8+4 configuration).
PoC: what it saves on install
Eight of the channels carry Power over Coax, so compatible HDCVI cameras get power and video down one coaxial run — no separate power cable to each camera position. The unit's total PoC budget is 48W, so on jobs with several high-draw cameras (long IR arrays, PTZ) tally the expected load against that figure before specifying.
Recording and storage
- Can capture 4K from analogue cameras and 8MP from IP cameras.
- H.265+ compression to cut storage/bandwidth demand on continuous-record setups
- One SATA bay, supporting drives up to 10TB
- HDMI output to 4K, with simultaneous VGA output for a secondary monitor
Where it fits
The channel count and PoC budget suit small retail units, single-office sites, or a warehouse loading bay covered by up to eight coax cameras plus a handful of IP additions — rather than large multi-building estates, where the 48W PoC ceiling and single-drive bay become limiting factors. Gigabit Ethernet and ONVIF support keep the door open to third-party IP cameras alongside Dahua's own range.
Also listed under DH-XVR5108H-4KL-X-8P-NO-HDD and DH-XVR5108H-4KL-X-8P+NO-HDD for no-HDD stock variants.
Specifications
- Brand
- Dahua
- Model
- XVR5108H-4KL-X-8P
- Series
- WizSense / XVR Series
- Channels
- 8
- Max Resolution
- 8MP (4K)
- Colour
- Black
- Video Compression
- H.265/H.264/H.265+/H.264+
- Frame Rate
- 7 fps @ 4K / 15 fps @ 4MP / 30 fps @ 1080p
- App Compatibility
- DMSS
- Camera Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any ONVIF-conformant IP camera.
- Storage Capacity
- Up to 10 TB
- Technology
- XVR
- Video Inputs
- TVI/AHD/CVI/CVBS/IP
- Video Outputs
- HDMI, VGA
- Human & Vehicle Detection
- Yes
- Face Detection
- No
- Face Recognition
- No
Technical Specifications
Frequently Asked Questions
How many cameras can the XVR5108H-4KL-X-8P power via PoC?
Up to 8 channels support Power over Coax, with a total PoC output budget of 48W across those channels.
Can this DVR run IP cameras alongside coax cameras?
Yes — it's a Penta-brid design supporting HDCVI, AHD, TVI, CVBS and IP cameras, and hybrid mode extends capacity to 12 IP inputs (8+4).
What's the maximum recording resolution?
Up to 4K from analogue cameras and up to 8MP from IP cameras.
How much storage can I fit?
The unit takes one SATA hard drive, supporting capacities up to 10TB.
