Unbranded - XVR-3108HS-5MP-LITE 8-Channel 5MP Lite Digital Video Recorder

The XVR-3108HS-5MP-LITE is an 8-channel Penta-brid DVR that suits small-to-mid installs where camera types might be mixed or upgraded over time. It accepts HDCVI, AHD, TVI, CVBS and IP inputs on the same unit, so a retail fit-out or office refurb can carry over existing analogue cameras while adding IP ones later without swapping the recorder.

Recording tops out at 5MP, with H.265+ compression keeping file sizes down — useful when the single SATA bay (up to 10TB) is the only local storage available. All 8 channels can play back synchronously, which matters for incident review across a full site rather than one camera at a time.

Key specs

• Channels: 8 analogue inputs, 1 audio (RCA)
• Resolution: up to 5MP per channel
• Inputs: HDCVI, AHD, TVI, CVBS, IP
• Storage: 1 × SATA, up to 10TB HDD
• Network: 1 × RJ-45, 10/100/1000Mbps
• USB: 2 × USB 2.0
• Operating range: -10°C to +55°C
• Power: 12V DC
• Dimensions: 315 × 45 × 240 mm, 1.2kg

Where it fits

Reasonable for residential blocks, retail units, warehouses and small industrial sites where 8 channels covers the camera count and a single-bay recorder is sufficient. For larger sites needing more than one HDD or higher channel counts, a different model in the range would be the better starting point.

Sold as the recorder unit only — pair it with your own HDD selection and camera lineup based on the inputs above.
