Product Description
The PXN-2108HS-8P-4K is an 8-channel 1U NVR with 8 built-in PoE ports, aimed at installers who want a self-contained recorder-and-power solution without a separate switch.
Fits the job
It suits retail units, small offices, warehouses and residential blocks running up to 8 IP cameras, where keeping cabling and hardware to a single 1U box simplifies the rack or cupboard install.
Key specs
- Video inputs: 8 IP channels, H.265/H.264 compression
- PoE: 8 ports, IEEE802.3at/af, up to 25.5W per port, 80W total budget
- Bandwidth: 80Mbps incoming
- Decoding: 1ch@8MP or 4ch@1080P, 30fps
- Display outputs: 1 HDMI (up to 3840×2160), 1 VGA, simultaneous output
- Storage: 1 SATA III port, up to 6TB per drive
- Network: 1 RJ-45 (10/100Mbps), ONVIF 2.4, SDK, CGI
- USB: 2 ports (1 rear USB2.0, 1 front USB2.0)
- Power: DC48V/1.25A single supply
Selection notes for installers
Because PoE budget is shared across 8 ports (80W total), plan camera load against the 25.5W per-port maximum when specifying high-draw cameras such as PTZ or IR-heavy models. Third-party IP camera support includes AXIS, Bosch, Panasonic, Pelco, Sony and others, useful where a site already has mixed-brand cameras. The single SATA III bay caps local storage at 6TB, so continuous multi-camera recording schedules should be sized accordingly before install.
Specifications
- Brand
- PROLUX
- Channels
- 8
- Colour
- Black
- Max Resolution
- 8 MP
- Storage Capacity
- Up to 10 TB
- Video Compression
- H.265/H.264
- Video Outputs
- HDMI, VGA
Technical Specifications
Frequently Asked Questions
How many PoE ports does the PXN-2108HS-8P-4K have?
It has 8 PoE ports (IEEE802.3at/af), with a maximum of 25.5W per port and 80W total budget.
What is the maximum recording resolution?
It supports resolutions up to 8MP, with decoding capacity of 1ch@8MP or 4ch@1080P at 30fps.
How much storage can it hold?
It has a single SATA III port supporting up to 6TB capacity.
Which third-party cameras does it support?
Listed compatible brands include AXIS, Bosch, Panasonic, Pelco, Sony, Samsung, Canon and others, via ONVIF 2.4, SDK and CGI.
