Product Description
At a glance
The IPBOX-GREY-240X180X130 is a grey PVC junction box rated IP65 — sealed against dust and protected against water jets — sized to house cable joints, terminal blocks or small power supplies outdoors.
Where it fits on a job
On a CCTV install, mid-run splices, power injectors and baluns need somewhere dry to sit rather than being left exposed on a wall or pole. This enclosure gives installers a wall-mountable housing at exactly that point — camera drops, NVR feed points, or general electrical junctions where two cable runs meet rather than one continuous pull.
Key specs
- IP rating: IP65 — dust-tight, protected against water jet ingress
- Material: durable PVC, suited to outdoor exposure
- Dimensions: 240 × 180 × 130 mm internal space
- Entry points: plain enclosure design — installers create their own cable entries to suit the run
- Mounting: wall-mountable
Practical selection notes
Choose this size when the job needs room for more than a single cable joint — terminal blocks, a small PSU, or slack cable coiled for future maintenance all fit within the 240 × 180 × 130 mm body. Because entry points aren't pre-cut, it adapts to whatever gland or grommet arrangement the installation calls for, useful when a spec isn't fixed until first fix stage.
Suits CCTV camera runs, network cabinet feeds, and general electrical junctions on any outdoor project — retail units, warehouses, offices or residential blocks — wherever a joint needs protecting from dust and water rather than a fresh unbroken cable run.
Specifications
- IP Rating
- IP65
- Dimensions
- 240 × 180 × 130 mm
- Colour
- Grey
Frequently Asked Questions
What level of IP protection does this junction box carry?
It is rated IP65, meaning it is dust-tight and protected against low-pressure water jets, suiting outdoor installation.
What size is the internal space?
The enclosure measures approximately 240 x 180 x 130 mm, giving room for terminal blocks, a small PSU and cable slack.
Are there pre-drilled cable entry points on the box?
No, the enclosure is a plain design so installers can create their own cable entry points to suit the specific run.
Can it be used for networking equipment as well as CCTV?
Yes, it is suitable for CCTV, networking and general electrical wiring installations that need outdoor protection.
