Product Description
A grey IP55 PVC junction box for housing cable joints and connectors on CCTV, networking and electrical installations that run outdoors or in exposed indoor areas.
What it's for
On a CCTV job this box typically sits at a camera drop, a cable run junction, or a point where a power lead meets a data cable, keeping the connection dry and out of sight. It suits retail shopfronts, warehouse external walls, office car parks and residential block installations where cabling has to cross from inside to outside.
Key specs
- Overall dimensions: 200 × 155 × 80 mm
- Ingress protection: Shields against dust and splashing water, rated IP55
- Material: durable PVC enclosure
- Design: adaptable, so installers can create their own cable entry points rather than relying on fixed knockouts
- Mounting: wall or surface mounted, with a secure cover for maintenance access
Selection notes
Because the enclosure is adaptable rather than pre-drilled, it's a practical choice where cable entry positions vary between sites — useful for engineers standardising on one box across multiple jobs. The 200 × 155 × 80 mm outer size gives a reasonable working area for terminal blocks and connectors, though wall thickness will reduce the usable internal space compared with the outer figure.
Pair it with appropriate cable glands to maintain the IP55 rating at entry points, since an unsealed hole will compromise the enclosure's dust and water resistance regardless of the box's own rating.
Specifications
- IP Rating
- IP55
- Dimensions
- 200 × 155 × 80 mm
- Colour
- Grey
Technical Specifications
Frequently Asked Questions
Are the 200 x 155 x 80mm dimensions internal or external?
These are the overall (outer) dimensions of the enclosure; the internal usable space will be slightly smaller once PVC wall thickness is accounted for.
Is this box suitable for outdoor CCTV cable connections?
Yes, it carries an IP55 rating, giving protection against dust ingress and water spray, and is designed for both indoor and outdoor installations.
Are there pre-drilled cable entry points on the box?
No, it's an adaptable enclosure — installers create their own cable entry points to suit the specific wiring layout on site.
What is the enclosure made from?
It's manufactured from durable PVC, chosen for reliable protection against environmental conditions in outdoor installations.
