Product Description
The SPL-2-6 joins one 2-wire feed to up to six outputs without a crimping tool, soldering iron or screwdriver on site. It's a lever wire connector with 2 input terminals and 6 output terminals, built for fast, reusable splicing inside junction boxes and enclosures.
Where it fits on a job
CCTV and electrical installers use connectors like this to distribute power or signal wiring from one supply point to multiple runs — useful when feeding several camera drops, illuminators or lighting circuit branches from a single cable inside a junction box or fitting. It suits lighting circuits, general electrical distribution wiring and control panel wiring as well as CCTV first-fix work.
How it works
Lift the lever, insert the stripped conductor, press the lever down — the connection is made with no tools. Because it's reusable, a wiring change or fault-find on site doesn't mean cutting the joint out; the lever releases and the conductor can be reinserted.
Key specs
- 2 input / 6 output terminals
- Tool-free lever-lock clamping mechanism
- Suitable for solid, stranded and flexible conductors
- Flame-retardant insulated housing with metal contacts
- Compact size for fitting inside junction boxes, lighting fittings and electrical enclosures
- Reusable for rewiring or modifications
Spec sheets, floor plans and existing wiring should confirm conductor type and box space before ordering in bulk for a first-fix run.
Specifications
- Model
- SPL-2-6-2
- Product Type
- Lever wire connector / splicing terminal
- Output Terminals
- 2
Frequently Asked Questions
How many wires is the SPL-2-6 able to join?
With 2 inputs and 6 outputs, a single supply can power up to six separate conductors.
Do I need tools to wire it?
No — it uses a tool-free lever-lock mechanism: lift the lever, insert the stripped conductor, then press the lever down to secure it.
Could I reuse it if I later have to re-wire the circuit?
Yes, it's a reusable connector, so the lever can be released and the conductor reinserted for modifications.
What conductor types does it accept?
It works with solid, stranded and flexible conductors alike.
