SPL-3-9-3 Grey Lever Wire Connector 3 In 9 Out Splicing Terminal

The SPL-3-9-3 is a 3-in, 9-out lever wire connector for splitting a single feed to multiple runs from one connection point. It suits jobs where several fittings need to share a supply from a common junction — lighting circuits, control wiring and general building distribution.

Where it fits on site

On retail and office fit-outs, this connector is typically used inside junction boxes or light fittings where one incoming cable needs to feed a run of luminaires or a group of control cables. On residential blocks and warehouses it does the same job at panel or enclosure level, cutting down the number of individual splices an installer has to make.

Handling and construction

The lever-lock mechanism means each conductor is secured by lifting and pressing a lever — no screwdriver, no crimping tool. That makes it useful where terminations need to be reworked during first fix or snagging, since the connector is reusable rather than a one-shot splice.

It accepts solid, stranded and flexible conductors, so it can bridge between different cable types on the same run. The housing is flame-retardant with copper internal contacts, and the compact body is sized to sit inside standard junction boxes, light fittings and control panels without crowding the enclosure.

Selection notes

Check terminal count against your circuit — 3 inputs and 9 outputs suits a single feed splitting to multiple branches, not a two-way splice.
