Universal Junction Box CCTV Camera Mount (Indoor & Outdoor/ Waterproof/ White)

Junction box mount for concealed CCTV wiring — MOUNT-AL-100X45-WHITE

MOUNT-AL-100X45-WHITE is an aluminium alloy junction box mount for CCTV cameras, built to house cable terminations behind the camera rather than leaving connectors exposed at a wall plate or gland.

Key specs

• Material: aluminium alloy
• Diameter: 100mm
• Depth: 45mm
• Wiring: 2 x side outlets for cable entry
• Included: mounting screws and cable glands
• Rating: waterproof, suitable for indoor and outdoor use
• Finish: white

Where it fits on a job

This is a universal base sized to suit a wide range of CCTV cameras rather than one specific model line, so it's a sensible stock item for engineers fitting mixed camera ranges across retail units, warehouses, offices and residential blocks. On outdoor runs, terminating cable inside the housing rather than in an open gland keeps connections protected from water and dust — useful on soffits, external walls and other exposed mounting points. The 45mm depth gives enough room behind the camera base for splicing or a small connector without a separate back box.

Before you order

Check the 100mm diameter against your camera's base fixing pattern, particularly on tight-tolerance dome or turret installs where the mount needs to sit flush. The white finish is intended to blend with common wall and soffit colours, so it suits jobs where the mount needs to stay visually low-key.
