Product Description
Fixed TV wall mount bracket (VESA 700x500, 32-80in) — TV-BRK-MOUNT-30-80-UNIVERSAL-DMI-3065-D-MARC
The TV-BRK-MOUNT-30-80-UNIVERSAL-DMI-3065-D-MARC is a fixed wall bracket for flat screen televisions from 32 to 80 inches, built for installers who need a straightforward, low-profile mount rather than a tilt or articulating arm.
Key specs
- VESA compatibility: up to 700 × 500 mm hole patterns
- Wall clearance: approximately 25 mm from wall
- Panel types: LED, LCD and flat panel TVs
- Construction: steel, for structural load support
- Movement: fixed — no tilt or swivel
- Fixing surfaces: concrete, brick or structural wall studs
Where it fits on a job
This bracket suits reception areas, meeting rooms, retail displays and living rooms where a large screen needs to sit flat and close to the wall with a tidy finish. Because there's no tilt or swivel mechanism, it's best specified where the screen height and viewing angle are already correct — public display areas and boardrooms are typical.
Selection notes for installers
Before ordering, confirm the target TV's actual VESA pattern falls within 700 × 500 mm and check the wall surface is suitable for steel-bracket fixings (concrete, brick or studs). Basic cable routing is possible behind the panel thanks to the 25 mm standoff, useful when tidying HDMI and power leads on commercial installs.
Specifications
- Dimensions
- 700 × 500 mm
- Screen Size
- 80"
Technical Specifications
Frequently Asked Questions
What's the largest VESA pattern this bracket can accommodate?
The TV-BRK-MOUNT-30-80-UNIVERSAL-DMI-3065-D-MARC supports VESA mounting patterns up to 700 × 500 mm.
Does this bracket tilt or swivel?
No — it is a fixed mount with no tilt or swivel movement, holding the TV at a set angle close to the wall.
What distance is the TV positioned away from the wall?
Approximately 25 mm, giving a slim, low-profile finish while still allowing basic cable management behind the panel.
What wall types is it suitable for?
It's designed for fixing to concrete, brick or structural wall studs, using its steel construction for stable support.
