Hikvision 8-Channel 2MP – 5MP CCTV Kit — 2 DS-2AE4225T-A 2MP PTZ + 2 DS-2CE78K0T-LPTS 5MP Turret Cameras + 4TB Recording (XVR-3108HS-5MP-LITE Recorder)
SKU: KIT-HD8-XVR3108HS5MP-DS2AE4225TADX04-4TB-1X76MCopied!
Built on: XVR-3108HS-5MP-LITE + 2× Hikvision DS-2AE4225T-A + 2× Hikvision DS-2CE78K0T-LPTS. Keeps about 30 days of continuous footage on the included 4TB surveillance hard drive.
Low Stock
Only 6 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a house — 4 cameras, keeps about 30 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Unbranded - XVR-3108HS-5MP-LITE 8-Channel 5MP Lite Digital Video Recorder
The box that saves everything and runs the app
The cameras× 2
Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome
What goes on the wall
The cameras× 2
Hikvision 3K Two Way Audio Fixed Turret
What goes on the wall
The hard drive
Toshiba S300 4TB Surveillance Hard Drive 3.5" SATA 5400RPM
Where the footage is kept
The power supply
18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
One plug that powers the cameras
The cable× 4
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 8-channel HD-over-coax CCTV kit built on the XVR-3108HS-5MP-LITE + 2× Hikvision DS-2AE4225T-A + 2× Hikvision DS-2CE78K0T-LPTS. 4 cameras at 2MP + 5MP — sized for a house or flat. The included 4TB surveillance hard drive holds about 30 days of continuous recording — the estimate assumes recording all 4 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Unbranded - XVR-3108HS-5MP-LITE 8-Channel 5MP Lite Digital Video Recorder; 2× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 2× Hikvision 3K Two Way Audio Fixed Turret; 1× Toshiba S300 4TB Surveillance Hard Drive 3.5" SATA 5400RPM; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit.
Specifications
- System type
- Analog (HD over coax)
- Built on
- XVR-3108HS-5MP-LITE + 2× Hikvision DS-2AE4225T-A + 2× Hikvision DS-2CE78K0T-LPTS
- Recorder
- 8-channel Unbranded - XVR-3108HS-5MP-LITE 8-Channel 5MP Lite Digital Video Recorder
- Cameras included
- 2× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 2× Hikvision 3K Two Way Audio Fixed Turret
- Camera resolution
- 2MP + 5MP
- Storage
- 4TB surveillance HDD — about 30 days of footage, recording all 4 cameras continuously at high quality (H.265) — the load is 2× 2MP + 2× 5MP
- Cables & PSU included
- 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- What's in the box
- 1× Unbranded - XVR-3108HS-5MP-LITE 8-Channel 5MP Lite Digital Video Recorder; 2× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 2× Hikvision 3K Two Way Audio Fixed Turret; 1× Toshiba S300 4TB Surveillance Hard Drive 3.5" SATA 5400RPM; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
