Raspberry Pi Zero WH with Pre-Soldered GPIO Header

Raspberry Pi Zero WH with Pre-Soldered GPIO Header

The Raspberry Pi Zero WH is a compact, affordable, and versatile single-board computer designed for electronics projects, automation, education, coding, and embedded applications. It offers the same convenient wireless connectivity as the Raspberry Pi Zero W, with the added benefit of a factory-fitted 40-pin GPIO header.

Because the GPIO header is already soldered in place, the Raspberry Pi Zero WH is ready to connect to HATs, sensors, displays, motors, relays, and other Raspberry Pi accessories without requiring any soldering. This makes it an excellent choice for beginners, students, developers, makers, and professional system integrators.

Compact Size with Reliable Performance

Powered by the Broadcom BCM2835 processor, the Raspberry Pi Zero WH runs at up to 1GHz. This processor is based on the same platform used in the original Raspberry Pi 1 but is clocked at a higher speed, offering approximately 40% improved performance.

With 512MB of RAM, the board is suitable for a wide range of lightweight computing, programming, networking, and automation tasks.

Its small form factor makes it especially useful for projects where space is limited, including portable electronics, smart-home devices, monitoring systems, robotics, digital signage, and custom control systems.

Built-In Wi-Fi and Bluetooth

The Raspberry Pi Zero WH includes built-in 802.11b/g/n wireless LAN, allowing it to connect directly to compatible Wi-Fi networks without requiring an external USB wireless adapter.

Bluetooth 4.1 and Bluetooth Low Energy connectivity are also built in, making it possible to connect compatible wireless keyboards, mice, controllers, sensors, and other Bluetooth-enabled devices.

These wireless features make the Raspberry Pi Zero WH ideal for Internet of Things applications, remote monitoring projects, wireless automation, and compact network-connected devices.

Pre-Soldered 40-Pin GPIO Header

The Raspberry Pi Zero WH features a HAT-compatible 40-pin GPIO header that is professionally pre-soldered onto the board.

This allows compatible Raspberry Pi HATs and electronic components to be connected immediately. The GPIO pins can be used to control or communicate with a wide variety of devices, including:

• Sensors
• LED lights
• Relays
• Motors
• Displays
• Buttons and switches
• Robotics components
• Home-automation equipment
• Custom electronic circuits

The pre-soldered header saves time and removes the need for specialist soldering tools, making the board easier and more convenient to use.

Mini HDMI Video Output

A Mini HDMI port provides digital video and audio output to a compatible monitor, television, or display.

A suitable Mini HDMI adapter or cable may be required depending on the display connection being used.

USB On-The-Go Connectivity

The Raspberry Pi Zero WH includes a Micro USB On-The-Go port for connecting compatible USB devices.

Using a suitable USB OTG adapter or hub, the board can be connected to accessories such as:

• Keyboards
• Mice
• USB storage devices
• Network adapters
• Controllers
• Other compatible USB peripherals

A separate Micro USB connection is provided for powering the board.

Camera Connectivity

The integrated CSI camera connector allows compatible Raspberry Pi camera modules to be connected.

This makes the Raspberry Pi Zero WH suitable for compact camera-based projects such as monitoring systems, time-lapse photography, wildlife cameras, machine-vision experiments, and educational imaging applications.

A compatible Raspberry Pi Zero camera cable may be required when connecting a camera module.

Composite Video and Reset Headers

The board includes composite video and reset header connection points, providing additional flexibility for custom installations and specialist electronic projects.

These connections can be particularly useful for embedded systems, custom enclosures, and projects requiring alternative video output or external reset controls.

Ideal for a Wide Range of Projects

The Raspberry Pi Zero WH is suitable for many different applications, including:

• Home automation
• Internet of Things projects
• Robotics
• Coding and programming practice
• Electronics education
• Network monitoring
• Smart displays
• Retro gaming projects
• Portable computing
• Camera projects
• Digital signage
• Custom control systems
• Embedded Linux applications
• Prototyping and product development

Key Features

• Raspberry Pi Zero WH model
• Factory pre-soldered 40-pin GPIO header
• Broadcom BCM2835 processor
• Processor speed up to 1GHz
• Approximately 40% faster than the original Raspberry Pi 1 platform
• 512MB RAM
• Built-in 802.11b/g/n wireless LAN
• Bluetooth 4.1
• Bluetooth Low Energy
• Mini HDMI output
• USB On-The-Go port
• Micro USB power input
• HAT-compatible GPIO connection
• CSI camera connector
• Composite video header
• Reset header
• Compact and lightweight design

The Raspberry Pi Zero WH combines compact dimensions, wireless connectivity, GPIO access, and flexible expansion options in one convenient board. Its pre-soldered header makes it ready for use in projects where quick setup, reliable connections, and easy accessory installation are important.
