Hikvision & Prolux 8-Channel 2MP – 4K CCTV Kit — 2 DS-2CE78U0T 4K Turret + 6 White HDT-2MP-N20W 2MP Dome Cameras + 10TB Recording (PXD-5208AN Recorder)
SKU: KIT-HD8-PXD5208AN4KL-DS2CE78U0TLPX08-10TB-GKI5HCopied!
Built on: Prolux PXD-5208AN-4KL-X-8P + 2× Hikvision DS-2CE78U0T-LPTS + 6× HDT-2MP-N20W-2.8MM. Keeps about 33 days of continuous footage on the included 10TB surveillance hard drive.
In Stock
Ready to ship • 19 available
How many cameras?
Same recorder and same cameras — just more of them.
Which camera styles?
The same kit, split differently between camera styles.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a shop or small business — 8 cameras, keeps about 33 days of footage, it reuses the round coax cable an older system left behind.
The recorder
ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder
The box that saves everything and runs the app
The cameras× 2
Hikvision 4K Two Way Audio Fixed Turret
What goes on the wall
The cameras× 6
2MP HD 4in1 Dome Camera (2.8mm/ White)
What goes on the wall
The hard drive
Toshiba S300 Pro 10TB Surveillance Hard Drive 3.5" SATA 7200RPM
Where the footage is kept
The power supply
12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
One plug that powers the cameras
The cable× 8
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 8-channel HD-over-coax CCTV kit built on the Prolux PXD-5208AN-4KL-X-8P + 2× Hikvision DS-2CE78U0T-LPTS + 6× HDT-2MP-N20W-2.8MM. 8 cameras at 2MP + 4K (8MP) — sized for a shop or small office. The included 10TB surveillance hard drive holds about 33 days of continuous recording — the estimate assumes recording all 8 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder; 2× Hikvision 4K Two Way Audio Fixed Turret; 6× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Toshiba S300 Pro 10TB Surveillance Hard Drive 3.5" SATA 7200RPM; 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Prolux PXD-5208AN-4KL-X-8P + 2× Hikvision DS-2CE78U0T-LPTS + 6× HDT-2MP-N20W-2.8MM
- Recorder
- 8-channel ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder
- Cameras included
- 2× Hikvision 4K Two Way Audio Fixed Turret; 6× 2MP HD 4in1 Dome Camera (2.8mm/ White)
- Camera resolution
- 2MP + 4K (8MP)
- Storage
- 10TB surveillance HDD — about 33 days of footage, recording all 8 cameras continuously at high quality (H.265) — the load is 2× 8MP + 6× 2MP
- Cables & PSU included
- 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed; 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- What's in the box
- 1× ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder; 2× Hikvision 4K Two Way Audio Fixed Turret; 6× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Toshiba S300 Pro 10TB Surveillance Hard Drive 3.5" SATA 7200RPM; 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
