Hikvision & Prolux 32-Channel 4MP – 5MP CCTV Kit — 1 5MP + 17 4MP Turret Cameras + 3× 8TB Recording
SKU: KIT-HD32-DS7332HQHIK4-DS2CE76H0TITX18-3X8TB-1COCVCopied!
Built on: Hikvision DS-7332HQHI-K4 + 1× Hikvision DS-2CE76H0T-ITMFS + 17× Prolux PXC-612C4W-A-POC. Keeps about 30 days of continuous footage on the included 3× 8TB hard drives (24TB in total).
Available to order
Add to basket or call us — our team will arrange it
How many cameras?
Same recorder and same cameras — just more of them.
How to buy this item: add it to your basket and send us a pricing request, or contact our sales team directly.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a commercial site — 18 cameras, keeps about 30 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 32-ch 5mp 1.5U H.265 DVR
The box that saves everything and runs the app
The cameras
Hikvision 5 MP Audio Fixed Turret Camera
What goes on the wall
The cameras× 17
Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible
What goes on the wall
The hard drive× 3
Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive
Where the footage is kept
The power supply
18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
One plug that powers the cameras
The cable× 18
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision DS-7332HQHI-K4 + 1× Hikvision DS-2CE76H0T-ITMFS + 17× Prolux PXC-612C4W-A-POC. 18 cameras at 4MP + 5MP — sized for a commercial site. The included 3× 8TB hard drives (24TB in total) hold about 30 days of continuous recording — the estimate assumes recording all 18 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when they fill. Power and cabling are covered: 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 1× Hikvision 5 MP Audio Fixed Turret Camera; 17× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible; 3× Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision DS-7332HQHI-K4 + 1× Hikvision DS-2CE76H0T-ITMFS + 17× Prolux PXC-612C4W-A-POC
- Recorder
- 32-channel Hikvision 32-ch 5mp 1.5U H.265 DVR
- Cameras included
- 1× Hikvision 5 MP Audio Fixed Turret Camera; 17× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible
- Camera resolution
- 4MP + 5MP
- Storage
- 3× 8TB (24TB total) HDD — about 30 days of footage, recording all 18 cameras continuously at high quality (H.265) — the load is 1× 5MP + 17× 4MP
- Cables & PSU included
- 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 1× Hikvision 5 MP Audio Fixed Turret Camera; 17× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible; 3× Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
