Hikvision 4-Channel 5MP CCTV Kit — 4 DS-2CE17K0T Bullet Cameras + 6TB Recording
SKU: KIT-HD4-IDS7204HUHIM-DS2CE17K0TLXX04-6TB-373VDCopied!
Built on: Hikvision iDS-7204HUHI-M1/XT + 4× Hikvision DS-2CE17K0T-LXTS. Keeps about 34 days of continuous footage on the included 6TB hard drive.
In Stock
Ready to ship • 11 available
How many cameras?
Same recorder and same cameras — just more of them.
How long should it keep footage?
When the drive fills, the recorder writes over the oldest day.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a house — 4 cameras, keeps about 34 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 4-ch 8 MP 1U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras× 4
Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera
What goes on the wall
The hard drive
Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E
Where the footage is kept
The power supply
12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
One plug that powers the cameras
The cable× 4
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 4-channel HD-over-coax CCTV kit built on the Hikvision iDS-7204HUHI-M1/XT + 4× Hikvision DS-2CE17K0T-LXTS. 4 cameras at 5MP — sized for a house or flat. The included 6TB hard drive holds about 34 days of continuous recording — the estimate assumes recording all 4 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 4-ch 8 MP 1U H.265 AcuSense DVR; 4× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera; 1× Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision iDS-7204HUHI-M1/XT + 4× Hikvision DS-2CE17K0T-LXTS
- Recorder
- 4-channel Hikvision 4-ch 8 MP 1U H.265 AcuSense DVR
- Cameras included
- 4× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera
- Camera resolution
- 5MP
- Storage
- 6TB HDD — about 34 days of footage, recording all 4 cameras continuously at high quality (H.265)
- Cables & PSU included
- 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 4-ch 8 MP 1U H.265 AcuSense DVR; 4× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera; 1× Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
