Hikvision & Dahua 4-Channel 5MP – 4K CCTV Kit — 1 4K + 2 5MP Bullet Cameras + 5TB Recording
SKU: KIT-HD4-DHXVR5104HS4-DS2CE12UF3TEX03-5TB-M6PB8Copied!
Built on: Dahua DH-XVR5104HS-4KL-I2 + 1× Hikvision DS-2CE12UF3T-E + 2× Hikvision DS-2CE17K0T-LXTS. Keeps about 28 days of continuous footage on the included 5TB hard drive.
Low Stock
Only 1 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a house — 3 cameras, keeps about 28 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Dahua WizSense XVR5104HS-I3 4 Channel 4K AI Penta-brid CCTV DVR
The box that saves everything and runs the app
The cameras
Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera
What goes on the wall
The cameras× 2
Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera
What goes on the wall
The hard drive
Lenovo ThinkServer 5TB 7.2K SATA 3.5" HDD 00LA954
Where the footage is kept
The power supply
12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
One plug that powers the cameras
The cable× 3
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 4-channel HD-over-coax CCTV kit built on the Dahua DH-XVR5104HS-4KL-I2 + 1× Hikvision DS-2CE12UF3T-E + 2× Hikvision DS-2CE17K0T-LXTS. 3 cameras at 5MP + 4K (8MP) — sized for a house or flat. The included 5TB hard drive holds about 28 days of continuous recording — the estimate assumes recording all 3 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 3× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Dahua WizSense XVR5104HS-I3 4 Channel 4K AI Penta-brid CCTV DVR; 1× Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera; 2× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera; 1× Lenovo ThinkServer 5TB 7.2K SATA 3.5" HDD 00LA954; 3× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug. Free DMSS app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Dahua DH-XVR5104HS-4KL-I2 + 1× Hikvision DS-2CE12UF3T-E + 2× Hikvision DS-2CE17K0T-LXTS
- Recorder
- 4-channel Dahua WizSense XVR5104HS-I3 4 Channel 4K AI Penta-brid CCTV DVR
- Cameras included
- 1× Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera; 2× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera
- Camera resolution
- 5MP + 4K (8MP)
- Storage
- 5TB HDD — about 28 days of footage, recording all 3 cameras continuously at high quality (H.265) — the load is 1× 8MP + 2× 5MP
- Cables & PSU included
- 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug; 3× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free DMSS app (iOS / Android) for live view and playback
- What's in the box
- 1× Dahua WizSense XVR5104HS-I3 4 Channel 4K AI Penta-brid CCTV DVR; 1× Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera; 2× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera; 1× Lenovo ThinkServer 5TB 7.2K SATA 3.5" HDD 00LA954; 3× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
