Hikvision & ANNKE 4-Channel 5MP – 4K CCTV Kit — 1 4K + 3 5MP Bullet Cameras + 6TB Recording
SKU: KIT-HD4-ANDV48MPD941-DS2CE12UF3TEX04-6TB-IK6X7Copied!
Built on: ANNKE AN-DV4-8MP-D941BB + 1× Hikvision DS-2CE12UF3T-E + 3× Hikvision DS-2CE17K0T-LXTS. Keeps about 27 days of continuous footage on the included 6TB hard drive.
Low Stock
Only 1 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a house — 4 cameras, keeps about 27 days of footage, it reuses the round coax cable an older system left behind.
The recorder
ANNKE D941BB – 8MP 4K 4-Channel 5-in-1 DVR
The box that saves everything and runs the app
The cameras
Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera
What goes on the wall
The cameras× 3
Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera
What goes on the wall
The hard drive
Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E
Where the footage is kept
The power supply
12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
One plug that powers the cameras
The cable× 4
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 4-channel HD-over-coax CCTV kit built on the ANNKE AN-DV4-8MP-D941BB + 1× Hikvision DS-2CE12UF3T-E + 3× Hikvision DS-2CE17K0T-LXTS. 4 cameras at 5MP + 4K (8MP) — sized for a house or flat. The included 6TB hard drive holds about 27 days of continuous recording — the estimate assumes recording all 4 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× ANNKE D941BB – 8MP 4K 4-Channel 5-in-1 DVR; 1× Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera; 3× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera; 1× Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug.
Specifications
- System type
- Analog (HD over coax)
- Built on
- ANNKE AN-DV4-8MP-D941BB + 1× Hikvision DS-2CE12UF3T-E + 3× Hikvision DS-2CE17K0T-LXTS
- Recorder
- 4-channel ANNKE D941BB – 8MP 4K 4-Channel 5-in-1 DVR
- Cameras included
- 1× Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera; 3× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera
- Camera resolution
- 5MP + 4K (8MP)
- Storage
- 6TB HDD — about 27 days of footage, recording all 4 cameras continuously at high quality (H.265) — the load is 1× 8MP + 3× 5MP
- Cables & PSU included
- 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- What's in the box
- 1× ANNKE D941BB – 8MP 4K 4-Channel 5-in-1 DVR; 1× Hikvision 4K ColorVu PoC Fixed Mini Bullet Camera; 3× Hikvision 3K Two Way Audio & Siren Fixed Bullet Camera; 1× Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
