Hikvision 32-Channel 2MP – 5MP CCTV Kit — 8 2MP PTZ + 16 5MP Bullet Cameras + 2× 12TB Recording
SKU: KIT-HD32-IDS7332HUHIM-DS2AE5225TIAX24-2X12TB-1KCN4Copied!
Built on: Hikvision iDS-7332HUHI-M4/S + 8× Hikvision DS-2AE5225TI-A-E + 16× Hikvision DS-2CE12KF3T-PIRXO. Keeps about 27 days of continuous footage on the included 2× 12TB surveillance hard drives (24TB in total).
Available to order
Add to basket or call us — our team will arrange it
How many cameras?
Same recorder and same cameras — just more of them.
Which camera styles?
The same kit, split differently between camera styles.
How to buy this item: add it to your basket and send us a pricing request, or contact our sales team directly.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a commercial site — 24 cameras, keeps about 27 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras× 8
Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera
What goes on the wall
The cameras× 16
HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera
What goes on the wall
The hard drive× 2
Toshiba N300 12TB NAS Hard Drive 3.5" SATA 7200RPM HDD
Where the footage is kept
The power supply× 2
18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit
One plug that powers the cameras
The cable× 24
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision iDS-7332HUHI-M4/S + 8× Hikvision DS-2AE5225TI-A-E + 16× Hikvision DS-2CE12KF3T-PIRXO. 24 cameras at 2MP + 5MP — sized for a commercial site. The included 2× 12TB surveillance hard drives (24TB in total) hold about 27 days of continuous recording — the estimate assumes recording all 24 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when they fill. Power and cabling are covered: 24× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR; 8× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 16× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 2× Toshiba N300 12TB NAS Hard Drive 3.5" SATA 7200RPM HDD; 24× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision iDS-7332HUHI-M4/S + 8× Hikvision DS-2AE5225TI-A-E + 16× Hikvision DS-2CE12KF3T-PIRXO
- Recorder
- 32-channel Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR
- Cameras included
- 8× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 16× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera
- Camera resolution
- 2MP + 5MP
- Storage
- 2× 12TB (24TB total) surveillance HDD — about 27 days of footage, recording all 24 cameras continuously at high quality (H.265) — the load is 8× 2MP + 16× 5MP
- Cables & PSU included
- 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit; 24× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR; 8× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 16× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 2× Toshiba N300 12TB NAS Hard Drive 3.5" SATA 7200RPM HDD; 24× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit
