Hikvision 32-Channel 2MP – 5MP CCTV Kit — 12 DS-2AE5225TI 2MP PTZ + 6 DS-2CE12KF0T 5MP Bullet Cameras + 2× 8TB Recording (DS-7332HQHI Recorder)
SKU: KIT-HD32-DS7332HQHIK4-DS2AE5225TIAX18-2X8TB-1MKACCopied!
Built on: Hikvision DS-7332HQHI-K4 + 12× Hikvision DS-2AE5225TI-A-E + 6× Hikvision DS-2CE12KF0T-LFS. Keeps about 30 days of continuous footage on the included 2× 8TB hard drives (16TB in total).
Discontinued
This product has been discontinued
How to buy this item: add it to your basket and send us a pricing request, or contact our sales team directly.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a commercial site — 18 cameras, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 32-ch 5mp 1.5U H.265 DVR
The box that saves everything and runs the app
The cameras× 12
Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera
What goes on the wall
The cameras× 6
Hikvision 3K ColorVu Smart hybrid light Fixed Bullet Camera
What goes on the wall
The hard drive× 2
Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive
Where the footage is kept
The power supply× 2
18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit
One plug that powers the cameras
The cable× 18
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision DS-7332HQHI-K4 + 12× Hikvision DS-2AE5225TI-A-E + 6× Hikvision DS-2CE12KF0T-LFS. 18 cameras at 2MP + 5MP — sized for a commercial site. The included 2× 8TB hard drives (16TB in total) hold about 30 days of continuous recording — the estimate assumes recording all 18 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when they fill. Power and cabling are covered: 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 2× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 12× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 6× Hikvision 3K ColorVu Smart hybrid light Fixed Bullet Camera; 2× Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision DS-7332HQHI-K4 + 12× Hikvision DS-2AE5225TI-A-E + 6× Hikvision DS-2CE12KF0T-LFS
- Recorder
- 32-channel Hikvision 32-ch 5mp 1.5U H.265 DVR
- Cameras included
- 12× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 6× Hikvision 3K ColorVu Smart hybrid light Fixed Bullet Camera
- Camera resolution
- 2MP + 5MP
- Storage
- 2× 8TB (16TB total) HDD — about 30 days of footage, recording all 18 cameras continuously at high quality (H.265) — the load is 12× 2MP + 6× 5MP
- Cables & PSU included
- 2× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 12× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 6× Hikvision 3K ColorVu Smart hybrid light Fixed Bullet Camera; 2× Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit
