Hikvision 32-Channel 2MP – 5MP CCTV Kit — 1 5MP Turret + 5 White 2MP Dome Cameras + 5TB Recording (IDS-7232HQHI Recorder)
SKU: KIT-HD32-IDS7232HQHIM-DS2CE76H0TITX06-5TB-16R7YCopied!
Built on: Hikvision iDS-7232HQHI-M2/XT + 1× Hikvision DS-2CE76H0T-ITMFS + 5× HDT-2MP-N20W-2.8MM. Keeps about 33 days of continuous footage on the included 5TB hard drive.
Low Stock
Only 3 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a shop or small business — 6 cameras, keeps about 33 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 32-ch 5MP1U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras
Hikvision 5 MP Audio Fixed Turret Camera
What goes on the wall
The cameras× 5
2MP HD 4in1 Dome Camera (2.8mm/ White)
What goes on the wall
The hard drive
Lenovo ThinkServer 5TB 7.2K SATA 3.5" HDD 00LA954
Where the footage is kept
The power supply
12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
One plug that powers the cameras
The cable× 6
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision iDS-7232HQHI-M2/XT + 1× Hikvision DS-2CE76H0T-ITMFS + 5× HDT-2MP-N20W-2.8MM. 6 cameras at 2MP + 5MP — sized for a shop or small office. The included 5TB hard drive holds about 33 days of continuous recording — the estimate assumes recording all 6 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 6× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 5MP1U H.265 AcuSense DVR; 1× Hikvision 5 MP Audio Fixed Turret Camera; 5× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Lenovo ThinkServer 5TB 7.2K SATA 3.5" HDD 00LA954; 6× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision iDS-7232HQHI-M2/XT + 1× Hikvision DS-2CE76H0T-ITMFS + 5× HDT-2MP-N20W-2.8MM
- Recorder
- 32-channel Hikvision 32-ch 5MP1U H.265 AcuSense DVR
- Cameras included
- 1× Hikvision 5 MP Audio Fixed Turret Camera; 5× 2MP HD 4in1 Dome Camera (2.8mm/ White)
- Camera resolution
- 2MP + 5MP
- Storage
- 5TB HDD — about 33 days of footage, recording all 6 cameras continuously at high quality (H.265) — the load is 1× 5MP + 5× 2MP
- Cables & PSU included
- 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed; 6× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 5MP1U H.265 AcuSense DVR; 1× Hikvision 5 MP Audio Fixed Turret Camera; 5× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Lenovo ThinkServer 5TB 7.2K SATA 3.5" HDD 00LA954; 6× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
