Product Description
A push-terminal DC 2.1mm female connector for CCTV and low-voltage 12V power runs. It terminates bare conductors without screwdrivers or solder, which suits first-fix and retrofit work where speed and repeatability matter on site.
Where it fits on a job
- Retail and office installs: mid-run joins inside junction boxes where a screw terminal would slow down a multi-camera first fix.
- Warehouses and residential blocks: extending or repairing 12V runs to cameras without re-crimping a plug.
- LED and power distribution: connecting bare-wire feeds into distribution points alongside camera power.
Compatibility
The jack accepts standard 5.5mm x 2.1mm DC male plugs, so it pairs with the male-plug side of most 12V CCTV power supplies and camera leads using that same barrel size. Confirm the barrel size on your existing plugs before ordering, since other DC barrel formats will not seat correctly.
Why installers choose push terminals
Push-button termination secures the conductor by insertion rather than a screw clamp, which speeds up panel and enclosure work and keeps connections consistent across a multi-point install. The inline body is compact enough for camera housings, junction boxes, and equipment enclosures where space is tight.
Keep this connector on the van for CCTV service calls and new-build power wiring where a fast, tool-free DC join is needed mid-cable rather than at a supply unit.
Specifications
- Voltage
- 12V
- Colour
- Red
Technical Specifications
Frequently Asked Questions
What plug size does this connector accept?
It accepts standard 5.5mm x 2.1mm DC male plugs, the common barrel size used on 12V CCTV power supplies and camera leads.
Do I need tools to wire it?
No — the push-button terminal lets you insert and secure the bare conductor without a screwdriver or soldering.
Where is this connector typically used?
In CCTV power wiring between supply units and cameras, and in power distribution boxes for junction and installation work.
Will it fit inside a camera housing or junction box?
Yes, it has a compact inline design intended for confined spaces such as junction boxes, camera housings, and equipment enclosures.
