Product Description
The Smart Fingerprint RFID Access Control Keypad IP65 suits side doors, plant rooms, communal entrances and staff-only areas where a wired keypad needs to sit outside without an enclosure. It reads fingerprints, RFID cards, PIN codes or a Bluetooth command from the Tuya app, so a site can mix credential types across different users without swapping hardware. The Bluetooth link works over a short local range rather than Wi-Fi, so no separate gateway is needed to pair a phone with the panel.
Where it fits a job
On commercial premises it typically pairs with a standard 12V door strike or maglock, drawing power from the same DC 12V supply feeding the rest of the entry system. The IP65 rating means the panel itself is sealed against dust and water jets, so it can go on an unsheltered exterior wall.
Key specs
- Working voltage: DC 12V, 500mA
- Fingerprint capacity: 300 users
- Card / password capacity: 1000 each, MF 1K compatible cards, 13.56MHz, 0–5cm read distance
- Panel: touch screen with white backlight
- Identification methods: fingerprint, RFID card, password, Bluetooth Tuya app
- Menu languages: Chinese, English, French, German, Spanish, Latin, Romanian, Italian
- Extras: wired doorbell input, remote door-opening log via the Tuya app
- Operating range: -20°C to 50°C, 20%–90% humidity
- Body: ABS plastic, 163×75×18mm (S300X)
For multi-tenant buildings, the 1000-card and 1000-password capacity allows separate credentials per unit without reprogramming the panel for each change of occupant.
Specifications
- IP Rating
- IP65
- Voltage
- 12V
- Material
- high quality ABS plastic
Frequently Asked Questions
What credential types does this keypad support?
It accepts fingerprint, 13.56MHz RFID card (MF 1K compatible), password entry, or a Bluetooth command from the Tuya app.
How many users can it store?
Up to 300 fingerprints plus 1000 card credentials and 1000 passwords.
Can it be fitted outdoors?
Yes, the panel carries an IP65 waterproof rating and an operating range of -20°C to 50°C.
What languages does the menu support?
The S300X panel menu supports Chinese, English, French, German, Spanish, Latin, Romanian and Italian.
