Hikvision & Prolux 8-Channel 5MP – 4K CCTV Kit — 1 DS-2CE12KF3T 5MP Bullet + 4 DS-2CE78U1T 4K Turret Cameras + 2× 6TB Recording
SKU: KIT-HD8-PXD5208AN4KL-DS2CE12KF3TPX05-2X6TB-JRHB7Copied!
Built on: Prolux PXD-5208AN-4KL-X-8P + 1× Hikvision DS-2CE12KF3T-PIRXO + 4× Hikvision DS-2CE78U1T-IT3F. Keeps about 30 days of continuous footage on the included 2× 6TB hard drives (12TB in total).
In Stock
Ready to ship • 12 available
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a shop or small business — 5 cameras, keeps about 30 days of footage, it reuses the round coax cable an older system left behind.
The recorder
ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder
The box that saves everything and runs the app
The cameras
HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera
What goes on the wall
The cameras× 4
Hikvision 4K Fixed Turret Camera
What goes on the wall
The hard drive× 2
Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E
Where the footage is kept
The power supply
12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
One plug that powers the cameras
The cable× 5
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 8-channel HD-over-coax CCTV kit built on the Prolux PXD-5208AN-4KL-X-8P + 1× Hikvision DS-2CE12KF3T-PIRXO + 4× Hikvision DS-2CE78U1T-IT3F. 5 cameras at 5MP + 4K (8MP) — sized for a shop or small office. The included 2× 6TB hard drives (12TB in total) hold about 30 days of continuous recording — the estimate assumes recording all 5 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when they fill. Power and cabling are covered: 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder; 1× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 4× Hikvision 4K Fixed Turret Camera; 2× Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Prolux PXD-5208AN-4KL-X-8P + 1× Hikvision DS-2CE12KF3T-PIRXO + 4× Hikvision DS-2CE78U1T-IT3F
- Recorder
- 8-channel ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder
- Cameras included
- 1× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 4× Hikvision 4K Fixed Turret Camera
- Camera resolution
- 5MP + 4K (8MP)
- Storage
- 2× 6TB (12TB total) HDD — about 30 days of footage, recording all 5 cameras continuously at high quality (H.265) — the load is 1× 5MP + 4× 8MP
- Cables & PSU included
- 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- What's in the box
- 1× ProLux PXD-5208AN-4KL-X/8P 8 Channel 4K Hybrid DVR PoC H.265+ Recorder; 1× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 4× Hikvision 4K Fixed Turret Camera; 2× Toshiba MG Series 6TB Enterprise Hard Drive 3.5" SATA 7200RPM -MG10ADA600E; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
