Hikvision 32-Channel 2MP – 5MP CCTV Kit — 13 5MP Bullet + 13 2MP Dome Cameras + 3× 8TB Recording
SKU: KIT-HD32-DS7332HQHIK4-DS2CE12KF3TPX26-3X8TB-17H0WCopied!
Built on: Hikvision DS-7332HQHI-K4 + 13× Hikvision DS-2CE12KF3T-PIRXO + 13× HDT-2MP-N20W-2.8MM. Keeps about 28 days of continuous footage on the included 3× 8TB hard drives (24TB in total).
Low Stock
Only 8 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a commercial site — 26 cameras, keeps about 28 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 32-ch 5mp 1.5U H.265 DVR
The box that saves everything and runs the app
The cameras× 13
HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera
What goes on the wall
The cameras× 13
2MP HD 4in1 Dome Camera (2.8mm/ White)
What goes on the wall
The hard drive× 3
Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive
Where the footage is kept
The power supply× 2
18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
One plug that powers the cameras
The cable× 26
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision DS-7332HQHI-K4 + 13× Hikvision DS-2CE12KF3T-PIRXO + 13× HDT-2MP-N20W-2.8MM. 26 cameras at 2MP + 5MP — sized for a commercial site. The included 3× 8TB hard drives (24TB in total) hold about 28 days of continuous recording — the estimate assumes recording all 26 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when they fill. Power and cabling are covered: 26× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 2× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 13× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 13× 2MP HD 4in1 Dome Camera (2.8mm/ White); 3× Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive; 26× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision DS-7332HQHI-K4 + 13× Hikvision DS-2CE12KF3T-PIRXO + 13× HDT-2MP-N20W-2.8MM
- Recorder
- 32-channel Hikvision 32-ch 5mp 1.5U H.265 DVR
- Cameras included
- 13× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 13× 2MP HD 4in1 Dome Camera (2.8mm/ White)
- Camera resolution
- 2MP + 5MP
- Storage
- 3× 8TB (24TB total) HDD — about 28 days of footage, recording all 26 cameras continuously at high quality (H.265) — the load is 13× 5MP + 13× 2MP
- Cables & PSU included
- 2× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit; 26× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 13× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 13× 2MP HD 4in1 Dome Camera (2.8mm/ White); 3× Western Digital Ultrastar 8TB Enterprise SATA 3.5" Hard Drive; 26× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
